| No. |
型號 Model |
|
GBM300 |
GBM360 |
GBM400 |
|||
|
1 |
自重 Dead weight |
T |
9 |
9.5 |
10.1 |
|||
|
2 |
額定起重量 Rated capacity |
Kg |
30000 |
36000 |
40000 |
|||
|
3 |
最大行駛速度（空載）max. steering speed(without load) |
Km/h |
3.5 |
3.5 |
3.5 |
|||
|
4 |
最小通道寬度 min. passageway width |
mm |
5400 |
5400 |
5400 |
|||
|
5 |
液壓馬達額定扭矩 rated torque of hydraulic motor |
Nm |
1010 |
1010 |
1010 |
|||
|
6 |
最大提升速度 max.lifting speed |
空載without load |
mm/s |
35 |
35 |
35 |
||
|
7 |
最大下降速度 max.falling speed |
mm/s |
25 |
25 |
25 |
|||
|
8 |
最大提升速度 max.lifting speed |
滿載 with load |
mm/s |
25 |
25 |
25 |
||
|
9 |
最大下降速度 max.falling speed |
mm/s |
30 |
30 |
30 |
|||
|
10 |
發動機功率 engine power |
Kw |
45 |
45 |
45 |
|||
|
11 |
系統壓力 system pressure |
Mpa |
14 |
15 |
16 |
|||
|
12 |
轉向輪旋轉角度 rotation angle of turning wheel |
° |
110 |
110 |
110 |
|||
|
13 |
長×寬×高 L*W*H |
mm |
6782×5133×6767 |
|||||
|
14 |
吊梁最大離地高度 max. height of lifting beam |
mm |
4459 |
4459 |
4459 |
|||
|
15 |
吊梁最低離地高度 lowest height of lifting beam |
mm |
2069 |
2069 |
2069 |
|||
|
16 |
橫向輪距 crosswise tread |
mm |
3725 |
3725 |
3725 |
|||
|
17 |
橫向內寬 inside width of crosswise |
mm |
3275/3380 |
3275/3380 |
3275/3380 |
|||
|
18 |
鋼絲繩直徑 wire rope diameter |
mm |
28 |
28 |
28 | |||
